2-103168-3

Conn Shrouded Header HDR 50POS 2.54mm Solder ST Thru-Hole

50 MODII HDR DRST SHRD .100CL

Product Highlights

Header

Header Type = Shrouded

Number of Rows = Dual

Number of Positions = 50

Mating Post Length = 8.08 mm

得捷:
CONN HEADER VERT 50POS 2.54MM

艾睿:
Are you looking for a solution to support physical configuration options on your PCB? Then mount this shrouded 2-103168-3 header connector from TE Connectivity on your PCB today! This HDR connector&s;s 50 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. This is a 2-row connector. Its pitch is 2.54 mm. It has a straight body orientation. This device has a maximum current rating of 3 A/contact. The item will be shipped in tray orientation. It uses the solder termination method. This connector has an operating temperature of -65 to 105 °C. 2-103168-3 is housed in black thermoplastic. This product is 66.34 mm long, 11.18 mm tall and 10.16 mm deep.

Verical:
Conn Shrouded Header HDR 50 POS 2.54mm Solder ST Thru-Hole Automotive Tray

Newark:
# AMP - TE CONNECTIVITY  2-103168-3  50 MODII HDR DRST SHRD .100CL New

MASTER:
HDR ASSY, MOD II, SHROUDED, 4 SIDES, DBL ROW, VERTICAL, .100X.100, WITH .025 SQ POSTS

Powell:
.100 inch AMPMODU Headers

Online Components:
50 MODII HDR DRST SHRD .100CL

Electro Sonic:
50 MODII HDR DRST SHRD .100CL
