250-402
数据手册.pdf
WAGO
连接器与适配器
WAGO 250-402 线至板接线端子, 2 路, 160 V, 4 A, 24 AWG, 20 AWG, 0.5 mm²
The is a 2-position PCB Terminal Block with polyamide 6.6 PA 6.6 insulator, 2.54mm pin spacing, copper alloy clamping spring and contacts tin-plated and grey colour. 0.5mm² cross-section, push-in wire connection method, 24 to 20AWG wire size and through hole 45° block orientation.
- .
- UL94V-0 Flammability rating
- .
- 2.5kV Measured shock voltage
- .
- Compact terminal strips with pushbuttons
- .
- Simple push-in termination for solid conductors
- .
- Termination/removal of fine-stranded conductors via push-buttons
- .
- Custom colour combinations
