电源电压DC 5.00 V, 5.50 V max
时钟频率 400kHz max
存取时间 900 ns
内存容量 2000 B
存取时间Max 900 ns
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 1.7V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 1.8 V
安装方式 Surface Mount
引脚数 8
封装 DFN-8
封装 DFN-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Contains Lead
24AA014T-I/MC引脚图
24AA014T-I/MC封装图
24AA014T-I/MC封装焊盘图
型号 | 制造商 | 描述 | 购买 |
---|---|---|---|
24AA014T-I/MC | Microchip 微芯 | 1K I2C ™串行EEPROM 1K I2C⑩ Serial EEPROM | 搜索库存 |
图片 | 型号/品牌/封装 | 代替类型 | 描述 | 替代型号对比 |
---|---|---|---|---|
型号: 24AA014T-I/MC 品牌: Microchip 微芯 封装: 8DFN 2000B 5V 400kHz | 当前型号 | 1K I2C ™串行EEPROM 1K I2C⑩ Serial EEPROM | 当前型号 | |
型号: 24AA014-I/MC 品牌: 微芯 封装: DFN-8 | 类似代替 | 24AA014/24LC014 I²C™ Serial EEPROMThe Microchip 24AA014/24LC014 range of devices are 1 Kbit I²C™ Serial EEPROMs available in a variety of package, temperature and power supply variants.### FeaturesSingle-Supply with Operation down to 1.7V – 24LC014 models only Low-Power CMOS Technology: 1 mA active current typical, 1 μA standby current typical at 5.5V Organized as a Single Block of 128 Bytes 128 x 8 Hardware Write Protection for Entire Array 2-Wire Serial Interface Bus, I2C™ Compatible 100 kHz and 400 kHz Clock Compatibility Page Write Buffer for up to 16 Bytes Self-Timed Write Cycle including auto-erase 5 ms max. Write Cycle Time Address Lines allow up to Eight Devices on Bus 1,000,000 Erase/Write Cycles ESD Protection > 4,000V Data Retention > 200 Years ### EEPROM 串行存取 - Microchip | 24AA014T-I/MC和24AA014-I/MC的区别 |
