24C02C/P

MICROCHIP  24C02C/P  EEPROM, 2 Kbit, 256K x 8位, 400 kHz, I2C, DIP, 8 引脚

The Technology Inc. 24C02C is a 2K bit Serial Electrically Erasable PROM with a voltage range of 4.5V to 5.5V. The device is organized as a single block of 256 x 8-bit memory with a 2-wire serial

interface. Low-current design permits operation with typical standby and active currents of only 10 μA and 1 mA, respectively. The device has a page write capability for up to 16 bytes of data and has fast write cycle

times of only 1 ms for both byte and page writes. Functional address lines allow the connection of up to eight 24C02C devices on the same bus for up to 16K bits of contiguous EEPROM memory. The device is

available in the standard 8-pin PDIP, 8-pin SOIC 150 mil, 8-pin 2x3 DFN, 8-pin MSOP and TSSOP packages.

* Self-timed Write Cycle and Page Write Mode

* Power On/Off Data Protection Circuitry

* Sequential Read Function
