1829992

Phoenix Contact PCB 接线端子块 COMBICON MCD 系列 6路 3.81mm节距 1829992, 焊接端接, 8A

Conn Shrouded Header HDR 12 POS 3.81mm Solder RA Thru-Hole

得捷:
TERM BLOCK HDR 12POS 3.81MM

欧时:
Phoenix Contact PCB 接线端子块 COMBICON MCD 系列 6路 3.81mm节距 1829992, 焊接端接, 8A

艾睿:
Use this shrouded 1829992 header connector from Phoenix Contact where IDC ribbon cables are used. This HDR connector has 12 contacts that are plated with tin. Its pitch is 3.81 mm. It has a right angle body orientation. It has a header type gender. This is a 2-row connector. It has a maximum voltage rating of 160 V. This device has a maximum current rating of 8 A. It uses the solder termination method. 1829992 is housed in green polyamide. This product is 24.25 mm long, 22.7 mm tall and 21.9 mm deep.

MASTER:
PCB headers - nominal current: 8 A - rated voltage III/2: 160 V - nominal cross section: 1.5 mm² - number of positions: 6 - pitch: 3.81 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.

Online Components:
Conn Shrouded Header HDR 12 POS 3.81mm Solder RA Thru-Hole

Electro Sonic:
PCB headers - nominal current: 8 A - rated voltage III/2: 160 V - nominal cross section: 1.5 mm² - ...
