1954731

Phoenix Contact PCB 接线端子块 COMBICON CC 系列 6路 5.08mm节距 1954731, 焊接端接, 12A

Conn Shrouded Header HDR 6 POS 5.08mm Solder RA Thru-Hole

得捷:
TERM BLOCK HDR 6POS 90DEG 5.08MM

欧时:
Phoenix Contact PCB 接线端子块 COMBICON CC 系列 6路 5.08mm节距 1954731, 焊接端接, 12A

贸泽:
Pluggable Terminal Blocks 6 Pos 5.08mm pitch Through Hole Header

艾睿:
Protect your printed circuit boards from accidental damages with Phoenix Contact&s;s shrouded 1954731 header connector. This HDR connector has 6 contacts that are plated with tin. It has a header type gender. It has a right angle body orientation. This is a 1-row connector. It has a maximum voltage rating of 320 V. Its pitch is 5.08 mm. This device has a maximum current rating of 12 A. 1954731 is housed in black liquid crystal polymer. This product is 40.64 mm long, 8.6 mm tall and 12 mm deep. It uses the solder termination method.

Verical:
Conn Shrouded Header 4 Sides HDR 6 POS 5.08mm Solder RA Thru-Hole

Online Components:
Conn Shrouded Header HDR 6 POS 5.08mm Solder RA Thru-Hole

Electro Sonic:
PCB headers - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - ...
