1-640457-4

Conn Wire to Board HDR 14POS 2.54mm Solder RA Thru-Hole

14P MTA100 HDR ASSY SQ R/A F/L

Product Highlights

MTA-100 Connectors

Number of Positions = 14

Mating Type = Header

Wire-to-Board Application

2.54 mm Contact Centerline Spacing

得捷:
CONN HEADER R/A 14POS 2.54MM

艾睿:
Are you looking for a solution to support physical configuration options on your PCB? Then mount this wire to board 1-640457-4 header connector from TE Connectivity on your PCB today! This HDR connector&s;s 14 contacts that are made out of copper alloy and plated with tin. It has a maximum voltage rating of 250 VAC. Its pitch is 2.54 mm. This is a 1-row connector. It has a header type gender. It has a right angle body orientation. This device has a maximum current rating of 5 A/contact. This connector has an operating temperature of -55 to 105 °C. This product is 35.56 mm long, 5.71 mm tall and 11.55 mm deep. It uses the solder termination method. 1-640457-4 is housed in white polyester.

Allied Electronics:
MTA-100 HEADER - TIN, 14P MTA100 HDR ASSY SQ R/A F/L

安富利:
Conn Wire to Board HDR 14 POS 2.54mm Solder RA Thru-Hole

Verical:
Conn Wire to Board HDR 14 POS 2.54mm Solder RA Thru-Hole Package

Newark:
# AMP - TE CONNECTIVITY  1-640457-4  14P MTA100 HDR ASSY SQ R/A F/L

MASTER:
MTA 100 HDR ASSY, FRICTION LOCK, NOTCHED, .025 SQUARE

Online Components:
14P MTA100 HDR ASSY SQ R/A F/L

Electro Sonic:
14P MTA100 HDR ASSY SQ R/A F/L
