1571983-5
数据手册.pdfTE CONNECTIVITY 1571983-5 DIP / SIP开关, SPST, SMD, 4 电路, DIP密封, 24 VDC
半间距摇臂
金擦触点系统
触点电阻:100mΩ
绝缘电阻:100 MΩ @ 250V 直流
薄型,胶袋密封
机械寿命:1000 次循环
### 注
以 STR04 结尾的部件号为胶带和卷装
欧时:
DIP switch,SMT,SPST,4 ps,recessed rocker
立创商城:
1571983-5
e络盟:
DIP / SIP开关, 4 电路, 滑动式, SMD, SPST, 24 VDC, 25 mA
艾睿:
Easily customize your printed circuit with the use of the 1571983-5 dual in-line package switch, designed from TE Connectivity. This device has a maximum current rating of 0.025 A @ 24VDC. It has a SPST configuration. This DIP switch has an operating temperature range of -30 °C to 85 °C. The 1571983-5 DIP switch has a gull wing termination style. The maximum DC voltage rating is 24 VDC. This product is 6.2 mm long, 2.3 mm tall and 8.13 mm deep. This product&s;s terminal pitch is 1.27 mm.
安富利:
Switch DIP ON OFF SPST 4 Recessed Slide 0.025A 24VDC Gull Wing 1.27mm SMD T/R
Chip1Stop:
Switch DIP ON OFF SPST 4 Recessed Rocker 0.025A 24VDC Gull Wing 1.27mm SMD T/R
Verical:
Switch DIP OFF ON SPST 4 Recessed Rocker 0.025A 24VDC Gull Wing 1.27mm SMD T/R
Newark:
# TE CONNECTIVITY 1571983-5 DIP Switch, SPST, DIP Sealed, SMD, 25 mA, 24 VDC
MASTER:
DIP / SIP Switch - 4 Circuits - Slide - SMD - SPST - 24 VDC - 25 mA.
Powell:
DIP, Rotary DIP, SIP Switches and DIP Shunts - Standard
Online Components:
GDH04STR04=DIP SWITCH
Electro Sonic:
DIP / SIP Switch - 4 Circuits - Slide - SMD - SPST - 24 VDC - 25 mA.
