1869253

Conn; Term Blk; PCB; Screw; 6; 5.08mm; 55Deg; 26-16AWG; 13.5A; 250V; Solder

6 接线板 - 线至板 55°（125°）角度，带板 0.200"（5.08mm） 通孔

得捷:
TERM BLOCK 6POS 55DEG 5.08MM PCB

贸泽:
Fixed Terminal Blocks 6P 5.08mm 145DEG

艾睿:
Easily mend a cutoff point in a circuit by using this pc terminal block 1869253 PCB terminal block from Phoenix Contact. This is a 1-row connector. Its pitch is 5.08 mm. It has a maximum voltage rating of 250 V. This device has a maximum current rating of 13.5 A. 1869253 is housed in polyamide. Its wire is 16-26 AWG. It uses the solder termination method. This product is 31.48 mm long, 11 mm tall and 12 mm deep.

Allied Electronics:
Conn; Term Blk; PCB; Screw; 6; 5.08 mm; 55 Deg; 26-16 AWG; 13.5 A; 250 V; Solder

Verical:
Conn PC Terminal Block 6 POS 5.08mm Solder Thru-Hole 13.5A

MASTER:
PCB terminal block - nominal current: 13.5 A - rated voltage III/2: 400 V - nominal cross section: 1.5 mm² - pitch: 5.08 mm - number of positions: 6 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB con

Online Components:
Conn PC Terminal Block 6 POS 5.08mm Solder Thru-Hole 13.5A

Electro Sonic:
PCB terminal block - nominal current: 13.5 A - rated voltage III/2: 400 V - nominal cross section: 1.5 mm² ...
