TSW-113-08-T-D-RA

SAMTEC TSW-113-08-T-D-RA Board-To-Board Connector, 2.54mm, 26Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔，直角 26 位置 0.100"（2.54mm）

得捷:
CONN HEADER R/A 26POS 2.54MM

艾睿:
Use this unshrouded TSW-113-08-T-D-RA connector from Samtec when board-to-board interconnects is required. This HDR connector&s;s 26 contacts that are made out of phosphor bronze and plated with tin over nickel. It has a maximum voltage rating of 450 VAC. It has a header type gender. It has a right angle body orientation. Its pitch is 2.54 mm. This is a 2-row connector. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. It uses the solder termination method. TSW-113-08-T-D-RA is housed in black polyester. This product is 33.02 mm long, 5.56 mm tall and 12.44 mm deep. This connector has an operating temperature of -55 to 105 °C.

安富利:
Conn Unshrouded Header HDR 26 POS 2.54mm Solder RA Thru-Hole

Newark:
# SAMTEC  TSW-113-08-T-D-RA  Board-To-Board Connector, 2.54 mm, 26 Contacts, Header, TSW Series, Through Hole, 2 Rows
