TLC1543IDBG4

10位模拟数字转换器带串行控制和11个模拟输入 10-BIT ANALOG-TO-DIGITAL CONVERTERS WITH SERIAL CONTROL AND 11 ANALOG INPUTS

DESCRIPON

The TLC1542C, TLC1542I, TLC1542M, TLC1542Q,TLC1543C, TLC1543I, and TLC1543Q are CMOS 10-bit switched-capacitor successive-approximation analog-to-digital converters.

FEATURES

• 10-Bit Resolution A/D Converter

• 11 Analog Input Channels

• Three Built-In Self-Test Modes

• Inherent Sample-and-Hold Function

• Total Unadjusted Error: ±1LSB Max

• On-Chip System Clock

• End-of-Conversion EOC Output

• Terminal Compatible With TLC542

• CMOS Technology
