TLV5625CDG4

TEXAS INSTRUMENTS  TLV5625CDG4  数模转换器, 双路, 8 bit, 93 kSPS, 串行, 2.7V 至 5.5V, SOIC, 8 引脚

The is a dual 8-bit voltage output Digital-to-analog Converter DAC with a flexible 3-wire serial interface. The serial interface is compatible with TMS320, SPI™, QSPI™ and MICROWIRE™ serial ports. It is programmed with a 16-bit serial string containing 4 control and 8 data bits. The resistor string output voltage is buffered by an x2 gain rail-to-rail output buffer. The buffer features a class-AB output stage to improve stability and reduce settling time. The programmable settling time of the DAC allows the designer to optimize speed versus power dissipation. Implemented with a CMOS process, the device is designed for single supply operation from 2.7 to 5.5V.

.

Programmable internal reference

.

Programmable settling time

.

Differential nonlinearity - <0.2LSB maximum

.

Monotonic over temperature
