TLV5624IDRG4
？ 2.7 V至5.5 V低功耗的8位数字 - 模拟转换器，具有内部基准和掉电 2.7-V TO 5.5-V LOW POWER 8-BIT DIGITAL-TO-ANALOG CONVERTER WITH INTERNAL REFERENCE AND POWER DOWN
description
The TLV5624 is a 8-bit voltage output DAC with a flexible 4-wire serial interface. The serial interface allows glueless interface to TMS320 and SPI, QSPI, and Microwire serial ports. It is programmed with a 16-bit serial string containing 4 control and 8 data bits.
features
• 8-Bit Voltage Output DAC
• Programmable Internal Reference
• Programmable Settling Time:
1 µs in Fast Mode,
3.5 µs in Slow Mode
• Compatible With TMS320 and SPI™ Serial Ports
• Differential Nonlinearity . . . <0.2 LSB
• Monotonic Over Temperature
applications
• Digital Servo Control Loops
• Digital Offset and Gain Adjustment
• Industrial Process Control
• Machine and Motion Control Devices
• Mass Storage Devices
