MAX3393EEUD+
数据手册.pdfMaxim Integrated(美信)
主动器件
MAXIM INTEGRATED PRODUCTS MAX3393EEUD+ 芯片, 逻辑转换器
The is a ±15KV ESD protected, 1µA quad channel low voltage level translator in 14 pin TSSOP package. ESD protected level translators provide the level shifting necessary to allow data transfer in a multivoltage system. Externally applied voltages VCC and VL set the logic levels on either side of the device. A low voltage logic signal present on the VL side of the device appears as a high voltage logic signal on the VCC side of the device and vice-versa.
- .
- Supply voltage range is 1.65V to 5.5V
- .
- Operating temperature range from -40°C to 85°C
- .
- Data rate is 8Mbps
- .
- Unidirectional level translation
- .
- Four receiver
- .
- Ultra low 1µA supply current in three state output mode
- .
- Low quiescent current of 130µA
- .
- Thermal short-circuit protection
