LM317LBD

3端正电压稳压器

100 mA Adjustable Output, Positive Voltage Regulator

The LM317L is an adjustable 3-terminal positive voltage regulator capable of supplying in excess of 100 mA over an output voltage range of 1.2V to 37 V. This voltage regulator is exceptionally easy to use and requires only two external resistors to set the output voltage. Further, it employs internal current limiting, thermal shutdown and safe area compensation, making them essentially blow-out proof.

The LM317L serves a wide variety of applications including local, on card regulation. This device can also be used to make a programmable output regulator, or by connecting a fixed resistor between the adjustment and output, the LM317L can be used as a precision current regulator.

Features

•Output Current in Excess of 100 mA

•Output Adjustable Between 1.2 V and 37 V

•Internal Thermal Overload Protection

•Internal Short Circuit Current Limiting

•Output Transistor Safe-Area Compensation

•Floating Operation for High Voltage Applications

•Standard 3-Lead Transistor Package

•Eliminates Stocking Many Fixed Voltages

•Pb-Free Packages are Available

•NCV Prefix for Automotive and Other Applications Requiring Site and Control Changes
