Harting Technology Group 哈丁电子 连接器

Conn D-Subminiature M 9POS Solder Cup ST Panel Mount 9 Terminal 1Port

In the automation industry, the Subminiature D connectors are the standard interfaces for data, signal and service / programmer interfaces. The extensive HARTING product range allows the set up of all Subminiature D interfaces common in the industry, including optional plastic and metal housings with IP 20 and IP 65 / IP 67 protection. These connectors have 9 to 50 contacts for panel mount to PCB or cable.


得捷:
CONN D-SUB PLUG 9POS PNL MNT


贸泽:
D-Sub Standard Connectors D SUB IP67 9 POLE STRAIGHT


艾睿:
Conn D-Subminiature M 9 POS Solder Cup ST Panel Mount 9 Terminal 1 Port


Allied Electronics:
D SUB IP 67_ 9 POLE STRAIGHT


09675099615中文资料参数规格
技术参数

触点数 9

额定电流 5 A

绝缘电阻 5000 MΩ

排数 2

针脚数 9

拔插次数 500

额定电流Max 5 A

接触电阻Max 10 mΩ

封装参数

安装方式 Panel

外形尺寸

高度 21 mm

物理参数

工作温度 -25℃ ~ 70℃

其他

产品生命周期 Active

包装方式 Tray

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

09675099615引脚图与封装图
暂无图片
在线购买09675099615
型号 制造商 描述 购买
09675099615 Harting Technology Group 哈丁电子 Conn D-Subminiature M 9POS Solder Cup ST Panel Mount 9 Terminal 1Port 搜索库存
