XG4A-4032

CONN PLUG 40POS 3A 300V STRT DIP

Conn Ejector Header PL 40 POS 2.54mm Solder ST Thru-Hole

得捷:
CONN HEADER VERT 40POS 2.54MM

艾睿:
Thanks to Omron&s;s ejector XG4A-4032 header connector, you can reduce the possibility of accidentally shorting out any pins on your printed circuit. This PL connector&s;s 40 contacts that are made out of brass and plated with gold over nickel. It has a plug type gender. This is a 2-row connector. It has a straight body orientation. Its pitch is 2.54 mm. It has a maximum voltage rating of 300 VAC. This device has a maximum current rating of 3 A. It uses the solder termination method. This product is 70.1 mm long, 23.3 mm tall and 8.5 mm deep. XG4A-4032 is housed in black polybutylene terephthalate. This connector has an operating temperature of -55 to 105 °C.

Allied Electronics:
Headers; Plug ShortLock 40P Straight 1Polarize

Chip1Stop:
Conn Ejector Header PL 40 POS 2.54mm Solder ST Thru-Hole

Newark:
# OMRON ELECTRONIC COMPONENTS  XG4A-4032  MIL-TYPE CONNECTOR

MASTER:
Conn Ejector Header PL 40 POS 2.54mm Solder ST Thru-Hole

Online Components:
Conn Ejector Header PL 40 POS 2.54mm Solder ST Thru-Hole

Electro Sonic:
Conn Ejector Header PL 40 POS 2.54mm Solder ST Thru-Hole
