OMRON ELECTRONIC COMPONENTS XF2J-2024-11A 连接器, FFC/ FPC板, XF系列, 20 触点, 插座, 0.5 mm, 表面安装
The is a 20-position 2-row ZIF Slide-locking Connector with gold-plated copper alloy contacts and a natural colour PA46 resin housing. It has black LCP resin slider and a tin-plated copper alloy hold-down. It is suitable for use with 0.3mm thickness FPC/FFC.
- .
- Correspond for auto-mounting, secured the pick-and-place on top of the connector
- .
- Standard terminals
- .
- 0.5A AC/DC Rated current
- .
- 50VAC/DC Rated voltage
- .
- 30mR Maximum contact resistance at 20mVDC maximum, 100mA maximum
- .
- 100MR at 250VDC Minimum insulation resistance
