VLF10045T-2R2N7R4
数据手册.pdf固定电感器
固定器
得捷:
FIXED IND 2.2UH 7.4A 10.2MOHM SM
艾睿:
Does your electronic circuit design require filtering, power supplies, and other similar functions? Then this power VLF10045T-2R2N7R4 surface mount inductor from TDK is perfect for you! This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 105 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. Its test frequency is 100K Hz. It has an inductance of 2.2u H. This product is 10.4 mm long, 4.5 mm tall and 10.1 mm deep. This device is made with wirewound technology. This SMD inductor has a maximum DC current of 7.4Typ A with a maximum resistance of 10.2m Ohm.
安富利:
Ind Power Shielded Wirewound 2.2uH 30% 100KHz 7.4A T/R
富昌:
VLF Series 2.2 uH ±30 % 7.4 A 10.2 mOhm SMT Shielded Wirewound Inductor
Chip1Stop:
Ind Power Shielded Wirewound 2.2uH 30% 100KHz 7.4A T/R
Verical:
Inductor Power Shielded Wirewound 2.2uH 30% 100KHz Ferrite 7.4A 0.0102Ohm DCR T/R
Win Source:
SMD InductorsCoils For Power LineWound, Magnetic Shielded | FIXED IND 2.2UH 7.4A 10.2 MOHM
