UC1825AJ883B
高速PWM控制器 High Speed PWM Controller
DESCRIPON
The UC3823A and UC3823B and the UC3825A and UC3825B family of PWM controllers are improved
versions of the standard UC3823 and UC3825 family. Performance enhancements have been made to several of the circuit blocks. Error amplifier gain bandwidth product is 12 MHz, while input offset voltage is 2 mV. Current limit threshold is assured to a tolerance of 5%.
FEATURES
Improved Versions of the UC3823/UC3825 PWMs
Compatible with Voltage-Mode or Current-Mode Control Methods
Practical Operation at Switching Frequencies to 1 MHz
50-ns Propagation Delay to Output
High-Current Dual Totem Pole Outputs 2-A Peak
Trimmed Oscillator Discharge Current
Low 100-μA Startup Current
Pulse-by-Pulse Current Limiting Comparator
Latched Overcurrent Comparator With Full Cycle Restart
