UPM1V561MHD1TO

Cap Aluminum Lytic 560uF 35V 20% 12.5 X 20mm Radial 5mm 1160mA 5000H 105℃ Ammo

560µF 35V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C

立创商城:
560uF ±20% 35V

得捷:
CAP ALUM 560UF 20% 35V RADIAL

艾睿:
The pure aluminum anode on the electrolytic UPM1V561MHD1TO electrolytic capacitor, designed from Nichicon, is the solution to your signal filtering needs. It can withstand a voltage of 35 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. It has a tolerance of 20%. Its leakage current is 588@1Min μA. This product is 20 mm tall with a diameter of 12.5 mm. This part has a lead diameter of 0.6 mm and a pitch of 5 mm. The UPM1V561MHD1TO aluminum electrolytic capacitor has a radial termination style. Its capacitance value is 560uF.

安富利:
Cap Aluminum 560uF 35V 20% 12.5 X 20mm Radial Aluminum Cylindrical Can 5mm 1430mA 5000hr 105°C Ammo Pack

Chip1Stop:
Cap Aluminum Lytic 560uF 35V 20% 12.5 X 20mm Radial 5mm 1160mA 5000h 105C Ammo Pack

Newark:
# NICHICON  UPM1V561MHD1TO  Electrolytic Capacitor, 560 µF, 35 V, PM Series, ± 20%, Radial Leaded, 12.5 mm
