UHE1H101MPD
数据手册.pdfHE 系列 105°CNichicon 的 HE 系列电解电容器可提供低阻抗、高稳定性、微型解决方案。 这些紧凑型电解电容器采用 PET（非 PVC）套管制成，带无铅引线。Temperature range | -40 to 105°C ---|--- Capacitance tolerance | ±20% 120Hz, 20°C Leakage current 2min | 0.01CV or 3μA, whichever is greater Life expectancy @ 105°C | > 4000 hours @ rated voltage and ripple current
HE Series 100 uF 50V 105°C Ř8 x 11.5mm LS=3.5mm Radial Aluminum Electrolytic Cap
欧时:
Capacitor Alu Radial -40°C to 105°C 50V
得捷:
CAP ALUM 100UF 20% 50V RADIAL
立创商城:
100uF ±20% 50V
贸泽:
Aluminum Electrolytic Capacitors - Leaded 50volts 100uF 8x11.5 20% 3.5LS
艾睿:
Cap Aluminum Lytic 100uF 50V 20% 8 X 11.5mm Radial 3.5mm 555mA 7000h 105°C Bulk
安富利:
Cap Aluminum 100uF 50V 20% 8 X 11.5mm Radial Aluminum Cylindrical Can 3.5mm 555mA 7000 hr 105°C Bulk
Chip1Stop:
Cap Aluminum Lytic 100uF 50V 20% 8 X 11.5mm Radial 3.5mm 555mA 7000h 105℃ Bulk
Verical:
Cap Aluminum Lytic 100uF 50V 20% 8 X 11.5mm Radial 3.5mm 555mA 7000h 105C Bulk
Newark:
# NICHICON UHE1H101MPD Electrolytic Capacitor, Miniature, 100 µF, 50 V, HE Series, ± 20%, Radial Leaded, 8 mm
