UWT1H220MCL1GB
数据手册.pdfNICHICON UWT1H220MCL1GB 铝电解电容, 22uF 50V SMD
铝电解器,WT 系列,105°C
宽工作范围 –55 到 +105°C 的片式工作。
额定电压范围为 4 至 50V
额定电容范围为 0.1 至 1500μF
设计用于表面安装到高密度 PC 板上。
适用于自动安装机器,用输送带送料。
符合 RoHS 指令 2011/65/EU。
WT 系列的无铅型号
工作温度范围 | -55 至 +105°C
---|---
电容容差 | ±20%(120 Hz,20°C)
泄漏电流 μA | 最大 0.01 CV 或 3(取较大值)(二分法)
高温负载特性 | 105°C 时为 1000 小时
得捷:
CAP ALUM 22UF 20% 50V SMD
欧时:
Nichicon 铝电解电容器 WT 系列 50V dc 22μF 表面安装器件 UWT1H220MCL1GB, ±20%容差, 最高+105°C
立创商城:
22uF ±20% 50V
贸泽:
Aluminum Electrolytic Capacitors - SMD 50volts 22uF 8x5.4 20%
e络盟:
铝电解电容, 22uF 50V SMD
艾睿:
By using pure aluminum foil in the anode, this electrolytic UWT1H220MCL1GB aluminum capacitor from Nichicon can easily filter low frequencies. It can withstand a voltage of 50 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. Its capacitance value is 22uF. This product is 5.4 mm tall with a diameter of 8 mm. It has a tolerance of 20%. Its leakage current is 11@2Min μA.
Allied Electronics:
22uF 50 V dc Aluminium Electrolytic Capacitor, WT Series 1000h 8 Dia. x 5.4mm
安富利:
Cap Aluminum 22uF 50V 20% 8 X 5.4mm SMD 51mA 1000 hr 105°C T/R
Chip1Stop:
Cap Aluminum Lytic 22uF 50V 20% 8 X 5.4mm SMD 51mA 1000h 105ÂÂ℃ T/R
TME:
Capacitor: electrolytic; SMD; 22uF; 50VDC; Ø8x5.4mm; ±20%; 1000h
Verical:
Cap Aluminum Lytic 22uF 50V 20% 8 X 5.4mm SMD 51mA 1000h 105C Automotive T/R
Newark:
# NICHICON UWT1H220MCL1GB SMD Aluminum Electrolytic Capacitor, Radial Can - SMD, 22 µF, 50 V, WT Series
