TC7WU04F

IC 反相器 TC7WU04F FM8 marking/标记 WU04F

3 inverter ;High speed: tpd = 6 ns typ. at VCC = 4.5 V • Low power dissipation: ICC = 1 μA max at Ta = 25°C • High noise immunity: VNIH = VNIL = 10% VCC min • Output drive capability: 10 LSTTL loads • Symmetrical output impedance: |IOH| = IOL = 4 mA min • Balanced propagation delays: tpLH −∼ tpHL • Wide operating voltage range: VCC opr = 2 to 6 V
