TSW-105-08-S-D-RA

SAMTEC TSW-105-08-S-D-RA Board-To-Board Connector, 2.54mm, 10Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔，直角 10 位置 0.100"（2.54mm）

得捷:
CONN HEADER R/A 10POS 2.54MM

欧时:
2.54mm TSW series R/A PCB pin header,10P

艾睿:
Support physical configuration options for jumper posts by mounting this unshrouded TSW-105-08-S-D-RA header connector from Samtec. This HDR connector&s;s 10 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. It has a header type gender. Its pitch is 2.54 mm. It has a right angle body orientation. It has a maximum voltage rating of 450 VAC. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. TSW-105-08-S-D-RA is housed in black polyester. This product is 12.7 mm long, 5.56 mm tall and 12.44 mm deep. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder RA Thru-Hole

Chip1Stop:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder RA Thru-Hole Bulk

Verical:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder RA Side Entry Thru-Hole Bulk

Newark:
# SAMTEC  TSW-105-08-S-D-RA  Board-To-Board Connector, 2.54 mm, 10 Contacts, Header, TSW Series, Through Hole, 2 Rows

Online Components:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder RA Thru-Hole Bulk

Electro Sonic:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder RA Thru-Hole Bulk
