TSW-105-08-S-D
数据手册.pdf集管和线壳 .100" Terminal Strip
Connector Header Through Hole 10 position 0.100" 2.54mm
欧时:
2.54mm TSW series PCB pin header, 10P
得捷:
CONN HEADER VERT 10POS 2.54MM
贸泽:
集管和线壳 .100" Terminal Strip
艾睿:
Protect your printed circuit boards from accidental damages with Samtec&s;s unshrouded TSW-105-08-S-D header connector. This HDR connector&s;s 10 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. It has a header type gender. It has a straight body orientation. It has a maximum voltage rating of 550 VAC. Its pitch is 2.54 mm. This device has a maximum current rating of 6.3 A/contact. TSW-105-08-S-D is housed in black polyester. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. This product is 12.7 mm long, 8.38 mm tall and 5.08 mm deep.
安富利:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder ST Thru-Hole
Verical:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder ST Thru-Hole Bag
Newark:
# SAMTEC TSW-105-08-S-D .025 Sq. Terminal Strips
