TSW-120-07-S-D

Board Connector, 40Contacts, 2 Rows, Male, Straight, 0.1inch Pitch, Solder Terminal, Black Insulator, Receptacle, ROHS COMPLIANT

针座 通孔 40 位置 0.100"（2.54mm）

欧时:
.100" Terminal Strip

得捷:
CONN HEADER VERT 40POS 2.54MM

艾睿:
Samtec&s;s unshrouded TSW-120-07-S-D header connector is a great way to reduce safety concerns in projects where there is a possibility of accidentally shorting electronic components. This HDR connector&s;s 40 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. It has a maximum voltage rating of 550 VAC. Its pitch is 2.54 mm. This is a 2-row connector. It has a straight body orientation. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. TSW-120-07-S-D is housed in black polyester. It uses the solder termination method. This product is 50.8 mm long, 8.38 mm tall and 5.08 mm deep. This connector has an operating temperature of -55 to 125 °C.

Newark:
# SAMTEC  TSW-120-07-S-D  .025 Sq. Terminal Strips
