TSW-132-07-S-D

Conn Unshrouded Header HDR 64POS 2.54mm Solder ST Thru-Hole

针座 通孔 64 位置 0.100"（2.54mm）

欧时:
HEADER TH 64POS 2 ROW

得捷:
CONN HEADER VERT 64POS 2.54MM

艾睿:
Protect your printed circuit boards from accidental damages with Samtec&s;s unshrouded TSW-132-07-S-D header connector. This HDR connector&s;s 64 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. It has a maximum voltage rating of 550 VAC. This is a 2-row connector. Its pitch is 2.54 mm. It has a header type gender. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. This product is 81.28 mm long, 8.38 mm tall and 5.08 mm deep. TSW-132-07-S-D is housed in black polyester.

安富利:
Conn Unshrouded Header HDR 64 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header HDR 64 POS 2.54mm Solder ST Top Entry Thru-Hole Bulk

Newark:
# SAMTEC  TSW-132-07-S-D  .025 Sq. Terminal Strips
