TD-130-G-A

SAMTEC TD-130G-A Board-To-Board Connector, 2.54mm, 60Contacts, Header, TD Series, Through Hole, 2Rows

针座 通孔 60 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 60POS 2.54MM

艾睿:
Use this unshrouded TD-130-G-A connector from Samtec when board-to-board interconnects is required. This HDR connector&s;s 60 contacts that are made out of brass and plated with gold over nickel. Its pitch is 2.54 mm. It has a header type gender. This is a 2-row connector. It has a straight body orientation. This device has a maximum current rating of 1 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This connector has an operating temperature of -55 to 125 °C. This product is 76.2 mm long, 8.16 mm tall and 5.08 mm deep. TD-130-G-A is housed in black polyester. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 60 POS 2.54mm Solder ST Thru-Hole Tube

Verical:
Conn Unshrouded Header HDR 60 POS 2.54mm Solder ST Top Entry Thru-Hole Tube

Newark:
# SAMTEC  TD-130-G-A  Board-To-Board Connector, 2.54 mm, 60 Contacts, Header, TD Series, Through Hole, 2 Rows
