TST-120-04-L-D-RA
数据手册.pdfSAMTEC TST-120-04-L-D-RA Wire-To-Board Connector, 2.54mm, 40Contacts, Header, TST Series, Through Hole, 2Rows
Connector Header Through Hole, Right Angle 40 position 0.100" 2.54mm
得捷:
CONN HEADER R/A 40POS 2.54MM
艾睿:
This shrouded TST-120-04-L-D-RA header connector from Samtec is used for jumper posts to support physical configuration options on printed circuit boards. This HDR connector&s;s 40 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. This is a 2-row connector. It has a right angle body orientation. Its pitch is 2.54 mm. This device has a maximum current rating of 3.4 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This connector has an operating temperature of -55 to 125 °C. This product is 58.42 mm long, 9.27 mm tall and 12.32 mm deep. TST-120-04-L-D-RA is housed in black polyester. It uses the solder termination method.
安富利:
Conn Shrouded Header HDR 40 POS 2.54mm Solder RA Thru-Hole Tube
Newark:
# SAMTEC TST-120-04-L-D-RA Wire-To-Board Connector, 2.54 mm, 40 Contacts, Header, TST Series, Through Hole, 2 Rows
Electro Sonic:
Conn Shrouded Header HDR 40 POS 2.54mm Solder RA Thru-Hole Tube
