TSW-108-12-G-S

SAMTEC TSW-108-12G-S Board-To-Board Connector, 2.54mm, 8Contacts, Header, TSW Series, Through Hole, 1Rows

针座 通孔 8 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 8POS 2.54MM

艾睿:
Make strong and binding connections on your circuit boards by adopting this unshrouded TSW-108-12-G-S connector from Samtec. This HDR connector&s;s 8 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 550 VAC. It has a header type gender. Its pitch is 2.54 mm. It has a straight body orientation. This is a 1-row connector. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. TSW-108-12-G-S is housed in black polyester. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. This product is 20.32 mm long, 8.38 mm tall and 2.54 mm deep.

安富利:
Conn Unshrouded Header HDR 8 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-108-12-G-S  Board-To-Board Connector, 2.54 mm, 8 Contacts, Header, TSW Series, Through Hole, 1 Rows
