TSW-116-15-T-S

SAMTEC TSW-116-15-T-S Board-To-Board Connector, 2.54mm, 16Contacts, Header, TSW Series, Through Hole, 1Rows

针座 通孔 16 位置 0.100"（2.54mm）

欧时:
.100" Terminal Strip

得捷:
CONN HEADER VERT 16POS 2.54MM

艾睿:
Easily mount this unshrouded TSW-116-15-T-S header connector from Samtec onto your PCB project to support a variety of physical configuration options. This HDR connector&s;s 16 contacts that are made out of phosphor bronze and plated with tin over nickel. Its pitch is 2.54 mm. It has a maximum voltage rating of 550 VAC. This is a 1-row connector. It has a straight body orientation. It has a header type gender. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 40.64 mm long, 15.75 mm tall and 2.54 mm deep. It uses the solder termination method. This connector has an operating temperature of -55 to 105 °C. TSW-116-15-T-S is housed in black polyester.

安富利:
Conn Unshrouded Header HDR 16 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-116-15-T-S  Board-To-Board Connector, 2.54 mm, 16 Contacts, Header, TSW Series, Through Hole, 1 Rows
