TSW-120-08-T-S-RA
数据手册.pdf2.54mm 方针
针座 通孔，直角 20 位置 0.100"（2.54mm）
欧时:
Classic PCB HDR Strips 0.100"
得捷:
CONN HEADER R/A 20POS 2.54MM
立创商城:
2.54mm 方针
艾睿:
Easily mount this unshrouded TSW-120-08-T-S-RA header connector from Samtec onto your PCB project to support a variety of physical configuration options. This HDR connector&s;s 20 contacts that are made out of phosphor bronze and plated with tin over nickel. It has a right angle body orientation. It has a maximum voltage rating of 450 VAC. It has a header type gender. This is a 1-row connector. Its pitch is 2.54 mm. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 105 °C. This product is 50.8 mm long, 3.02 mm tall and 9.9 mm deep. It uses the solder termination method. TSW-120-08-T-S-RA is housed in black polyester.
Newark:
# SAMTEC TSW-120-08-T-S-RA Board-To-Board Connector, 2.54 mm, 20 Contacts, Header, TSW Series, Through Hole, 1 Rows
