TSW-106-25-F-S-RA

SAMTEC TSW-106-25F-S-RA Board-To-Board Connector, 2.54mm, 6Contacts, Header, TSW Series, Through Hole, 1Rows

针座 通孔，直角 6 位置 0.100"（2.54mm）

得捷:
CONN HEADER R/A 6POS 2.54MM

欧时:
HEADER R/A 6POS 2.54MM 1 ROW

艾睿:
Use this unshrouded TSW-106-25-F-S-RA header connector from Samtec where IDC ribbon cables are used. This HDR connector&s;s 6 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. It has a right angle body orientation. It has a maximum voltage rating of 450 VAC. This is a 1-row connector. Its pitch is 2.54 mm. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 125 °C. This product is 15.24 mm long, 3.02 mm tall and 12.19 mm deep. It uses the solder termination method. TSW-106-25-F-S-RA is housed in black polyester.

安富利:
Conn Unshrouded Header HDR 6 POS 2.54mm Solder RA Thru-Hole

Verical:
Conn Unshrouded Header HDR 6 POS 2.54mm Solder RA Side Entry Thru-Hole Bulk

Newark:
# SAMTEC  TSW-106-25-F-S-RA  Board-To-Board Connector, 2.54 mm, 6 Contacts, Header, TSW Series, Through Hole, 1 Rows
