TSW-110-15-T-S

SAMTEC TSW-110-15-T-S Board-To-Board Connector, 2.54mm, 10Contacts, Header, TSW Series, Through Hole, 1Rows

针座 通孔 10 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 10POS 2.54MM

欧时:
HEADER TH 10POS 2.54MM 1 ROW

艾睿:
Safety is an important concern when designing electronic devices. Samtec&s;s unshrouded TSW-110-15-T-S header connector helps protect your equipment from accidental shortages. This HDR connector&s;s 10 contacts that are made out of phosphor bronze and plated with tin over nickel. Its pitch is 2.54 mm. It has a header type gender. This is a 1-row connector. It has a maximum voltage rating of 550 VAC. It has a straight body orientation. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 25.4 mm long, 15.75 mm tall and 2.54 mm deep. This connector has an operating temperature of -55 to 105 °C. TSW-110-15-T-S is housed in black polyester. It uses the solder termination method.

Newark:
# SAMTEC  TSW-110-15-T-S  Board-To-Board Connector, 2.54 mm, 10 Contacts, Header, TSW Series, Through Hole, 1 Rows
