TSW-112-17-T-S

SAMTEC TSW-112-17-T-S Board-To-Board Connector, 2.54mm, 12Contacts, Header, TSW Series, Through Hole, 1Rows

针座 通孔 12 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 12POS 2.54MM

艾睿:
Samtec brings you their unshrouded TSW-112-17-T-S header connector, an important safety tool for protecting your electronic components from accidental damage. This HDR connector&s;s 12 contacts that are made out of phosphor bronze and plated with tin over nickel. It has a maximum voltage rating of 550 VAC. This is a 1-row connector. Its pitch is 2.54 mm. It has a header type gender. It has a straight body orientation. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. TSW-112-17-T-S is housed in black polyester. This connector has an operating temperature of -55 to 105 °C. This product is 30.48 mm long, 18.28 mm tall and 2.54 mm deep. It uses the solder termination method.

Newark:
# SAMTEC  TSW-112-17-T-S  Board-To-Board Connector, 2.54 mm, 12 Contacts, Header, TSW Series, Through Hole, 1 Rows
