TMM-109-01-G-S

Conn Unshrouded Header HDR 9POS 2mm Solder ST Thru-Hole

针座 通孔 9 位置 0.079"（2.00mm）

得捷:
CONN HEADER VERT 9POS 2MM

艾睿:
Mounting this unshrouded TMM-109-01-G-S header connector from Samtec to your printed circuit board can help you support multiple physical configuration options. This HDR connector&s;s 9 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 1-row connector. It has a maximum voltage rating of 500 VAC. It has a header type gender. Its pitch is 2 mm. It has a straight body orientation. This device has a maximum current rating of 5.5 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. It uses the solder termination method. This product is 18 mm long, 4.7 mm tall and 1.97 mm deep. TMM-109-01-G-S is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Unshrouded Header HDR 9 POS 2mm Solder ST Thru-Hole
