TSW-103-23-S-D

Conn Unshrouded Header HDR 6POS 2.54mm Solder ST Thru-Hole

针座 通孔 6 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 6POS 2.54MM

艾睿:
Mount this unshrouded TSW-103-23-S-D header connector from Samtec on a jumper post on your PCB to support physical configuration options. This HDR connector&s;s 6 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 550 VAC. It has a header type gender. This is a 2-row connector. Its pitch is 2.54 mm. It has a straight body orientation. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. This product is 7.62 mm long, 8.38 mm tall and 5.08 mm deep. TSW-103-23-S-D is housed in black polyester.

安富利:
Conn Unshrouded Header HDR 6 POS 2.54mm Solder ST Thru-Hole
