TMM-150-01-T-S-SM

Conn Unshrouded Header HDR 50POS 2mm Solder ST SMD Tube

针座 表面贴装型 50 位置 0.079"（2.00mm）

得捷:
CONN HEADER SMD 50POS 2MM

欧时:
2.00 mm Low Profile Terminal Strip

艾睿:
Support physical configuration options for jumper posts by mounting this unshrouded TMM-150-01-T-S-SM header connector from Samtec. This HDR connector&s;s 50 contacts that are made out of phosphor bronze and plated with matte tin over nickel. It has a straight body orientation. This is a 1-row connector. Its pitch is 2 mm. It has a header type gender. It has a maximum voltage rating of 500 VAC. This device has a maximum current rating of 3.2 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. TMM-150-01-T-S-SM is housed in black liquid crystal polymer. This product is 100 mm long, 5.97 mm tall and 4.83 mm deep. It uses the solder termination method. This connector has an operating temperature of -55 to 105 °C.
