TLV1117-33IDRJRG4
TI
德州仪器
主动器件
可调，固定低压差稳压器 ADJUSTABLE AND FIXED LOW-DROPOUT VOLTAGE REGULATOR
description
The TLV1117 is a positive low-dropout voltage regulator, designed to provide up to 800 mA of output current. The device is available in 1.5 V, 1.8 V, 2.5 V, 3.3 V, 5 V, and adjustable output voltage options. All internal circuitry is designed to operate down to 1-V input-to-output differential. Dropout voltage is specified at a maximum of 1.3 V at 800 mA, decreasing at lower load currents. 1.5 V, 1.8 V, 2.5 V, 3.3 V, 5 V, and Adjustable
Output Voltage Options
Output Current of 800 mA
Operates Down to 1.1-V Dropout
Specified Dropout Voltage at Multiple Current Levels
0.2% Line Regulation Maximum
0.4% Load Regulation Maximum
