TLE2142ACDRG4

EXCALIBUR低噪声高速精密运算放大器 EXCALIBUR LOW-NOISE HIGH-SPEED PRECISION OPERATIONAL AMPLIFIERS

description

The TLE214x and TLE214xA devices are high-performance, internally compensated operational amplifiers

built using Texas Instruments complementary bipolar Excalibur process. The TLE214xA is a tighter offset

voltage grade of the TLE214x. Both are pin-compatible upgrades to standard industry products.

Low Noise

  10 Hz . . . 15 nV/√Hz

  1 kHz . . . 10.5 nV/√Hz

10000-pF Load Capability

20-mA Min Short-Circuit Output Current

27-V/µs Min Slew Rate

High Gain-Bandwidth Product. . . 5.9 MHz

Low VIO . . . 500 µV Max at 25°C

Single or Split Supply...4 V to 44 V

Fast Settling Time

  340 ns to 0.1%

  400 ns to 0.01%

Saturation Recovery. . . 150 ns

Large Output Swing

  VCC−+0.1 V to VCC+− 1 V
