TLV27L2IDGKRG4

运算放大器 - 运放 11-uA/Ch 160kHz RR-Out Dual Op Amp

DESCRIPON

The TLV27Lx single supply operational amplifiers provide rail-to-rail output capability. The TLV27Lx takes

the minimum operating supply voltage down to 2.7 V over the extended industrial temperature range, while adding the rail-to-rail output swing feature. The TLV27Lx also provides 160-kHz bandwidth from only 7µA. The maximum recommended supply voltage is 16 V, which allows the devices to be operated from ±8-V supplies down to ±1.35 V two rechargeable cells.

FEATURES

BiMOS Rail-to-Rail Output

Input Bias Current...1 pA

High Wide Bandwidth...160 kHz

High Slew Rate...0.1 V/µs

Supply Current...7 µA per channel

Input Noise Voltage ...89 nV/√Hz

Supply Voltage Range...2.7 V to 16 V

Specified Temperature Range

  – –40°C to 125°C...Industrial Grade

  – 0°C to 70°C...Commercial Grade

Ultra-Small Packaging

  – 5 Pin SOT-23 TLV27L1

APPLICATIONS

Portable Medical

Power Monitoring

Low Power Security Detection Systems

Smoke Detectors
