TSW-101-07-G-Q

SAMTEC TSW-101-07-G-Q Board-To-Board Connector, 2.54mm, 2Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔 2 位置 -

得捷:
CONN HEADER VERT 2POS

艾睿:
As an added safety precaution, the unshrouded TSW-101-07-G-Q header connector from Samtec will prevent and protect components on your circuit board from accidentally touching each other. This HDR connector&s;s 2 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. It has a maximum voltage rating of 550 VAC. It has a straight body orientation. It has a header type gender. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. TSW-101-07-G-Q is housed in black polyester. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. This product is 2.54 mm long, 8.38 mm tall and 7.62 mm deep.

安富利:
Conn Unshrouded Header HDR 2 POS Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-101-07-G-Q  Board-To-Board Connector, 2.54 mm, 2 Contacts, Header, TSW Series, Through Hole, 2 Rows
