TSW-102-17-L-S

2.54mm 方针

针座 通孔 2 位置 0.100"（2.54mm）

立创商城:
2.54mm 方针

得捷:
CONN HEADER VERT 2POS 2.54MM

艾睿:
Think of Samtec&s;s unshrouded TSW-102-17-L-S header connector the next time you&s;re concerned about accidentally shorting out pins on your printed circuit. This HDR connector&s;s 2 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 1-row connector. It has a maximum voltage rating of 550 VAC. It has a header type gender. It has a straight body orientation. Its pitch is 2.54 mm. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 125 °C. This product is 5.08 mm long, 18.28 mm tall and 2.54 mm deep. It uses the solder termination method. TSW-102-17-L-S is housed in black polyester.

安富利:
Conn Unshrouded Header HDR 2 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-102-17-L-S  Board-To-Board Connector, 2.54 mm, 2 Contacts, Header, TSW Series, Through Hole, 1 Rows
