TSW-102-07-T-D
数据手册.pdf板至板连接, 2.54 mm, 4 触点, 针座, TSW Series, 通孔安装, 2 排
针座 通孔 4 位置 0.100"（2.54mm）
欧时:
2.54mm TSW series PCB pin header, 4P
得捷:
CONN HEADER 4POS .100" DUAL TIN
艾睿:
Samtec brings you their unshrouded TSW-102-07-T-D header connector, an important safety tool for protecting your electronic components from accidental damage. This HDR connector&s;s 4 contacts that are made out of phosphor bronze and plated with tin over nickel. This is a 2-row connector. It has a header type gender. It has a maximum voltage rating of 550 VAC. It has a straight body orientation. Its pitch is 2.54 mm. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. TSW-102-07-T-D is housed in black polyester. It uses the solder termination method. This connector has an operating temperature of -55 to 105 °C. This product is 5.08 mm long, 8.38 mm tall and 5.08 mm deep.
安富利:
Conn Unshrouded Header HDR 4 POS 2.54mm Solder ST Thru-Hole
Verical:
Conn Unshrouded Header HDR 4 POS 2.54mm Solder ST Top Entry Thru-Hole Bag
Newark:
# SAMTEC TSW-102-07-T-D Board-To-Board Connector, 2.54 mm, 4 Contacts, Header, TSW Series, Through Hole, 2 Rows
