SSM-118-L-DV

Conn Socket Strip SKT 36POS 2.54mm Solder ST SMD Tube

36 位置 插座，通透式 0.100"（2.54mm） 表面贴装型 镀金

得捷:
CONN RCPT 36POS 0.1 GOLD SMD

艾睿:
Reduce safety concerns with this socket strip SSM-118-L-DV header connector from Samtec which will reduce the possibility of accidentally shorting pins when a printed circuit board is being used. This SKT connector&s;s 36 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 510 VDC|360VAC. It has a straight body orientation. This is a 2-row connector. Its pitch is 2.54 mm. It has a socket type gender. This device has a maximum current rating of 5.2 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It uses the solder termination method. This product is 45.72 mm long, 7.37 mm tall and 7.04 mm deep. This connector has an operating temperature of -55 to 125 °C. SSM-118-L-DV is housed in black liquid crystal polymer.

安富利:
Conn Socket Strip SKT 36 POS 2.54mm Solder ST SMD Tube

Newark:
# SAMTEC  SSM-118-L-DV  Board-To-Board Connector, 2.54 mm, 36 Contacts, Receptacle, SSM Series, Surface Mount, 2 Rows
