SLW-110-01-S-S

SAMTEC SLW-110-01-S-S Board-To-Board Connector, 2.54mm, 10Contacts, Receptacle, SLW Series, Through Hole, 1Rows

10 Position Receptacle Connector Through Hole

得捷:
CONN RCPT 10POS 0.1 GOLD PCB

艾睿:
This socket strip SLW-110-01-S-S header connector from Samtec is used for jumper posts to support physical configuration options on printed circuit boards. This SKT connector&s;s 10 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. Its pitch is 2.54 mm. This is a 1-row connector. It has a socket type gender. It has a maximum voltage rating of 50 VAC. This device has a maximum current rating of 5.2 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 25.4 mm long, 4.57 mm tall and 2.54 mm deep. SLW-110-01-S-S is housed in black polyester. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method.

安富利:
Conn Socket Strip SKT 10 POS 2.54mm Solder ST Thru-Hole

Chip1Stop:
Conn Socket Strip SKT 10 POS 2.54mm Solder ST Thru-Hole Bulk

Newark:
# SAMTEC  SLW-110-01-S-S  Board-To-Board Connector, 2.54 mm, 10 Contacts, Receptacle, SLW Series, Through Hole, 1 Rows

Electro Sonic:
Conn Socket Strip SKT 10 POS 2.54mm Solder ST Thru-Hole Bulk
