SRP1038A-R39M

BOURNS  SRP1038A-R39M  表面贴装功率电感器, AEC-Q200 SRP1038A系列, 390 nH, ± 20%, 屏蔽, 1300 µohm, 30 A

SRP1038A 系列磁性屏蔽式功率器

SRP1038A 系列电感器为屏蔽结构

羰基粉芯

高饱和电流

电感范围为 0.22 至 47μH

应用包括汽车系统（驾驶员辅助、信息、娱乐和照明）、直流/直流转换器和电源

立创商城:
390nH ±20% 30A 1.1mΩ

得捷:
FIXED IND 390NH 30A 1.3 MOHM SMD

欧时:
Bourns SRP1038A 系列 屏蔽 羰基粉芯材 390 nH 绕线贴片电感器 SRP1038A-R39M, ±20%容差, 30A Idc

e络盟:
功率电感SMD, 390 nH, 30 A, 屏蔽, 60 A, SRP1038A 系列, 11mm x 10mm x 3.8mm

艾睿:
Is space on a PCB a limiting factor for your electronic circuit design? Then use this power SRP1038A-R39M surface mount inductor from Bourns to save valuable space. This SMD inductor has an operating temperature range of -40 °C to 150 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 100MTyp Hz. This product is 11.5 mm long, 4 mm tall and 10.3 mm deep. It has a tolerance of 20%. This device utilizes wirewound technology. This SMD inductor has a maximum DC current of 30 A with a maximum resistance of 1.3m Ohm. It has an inductance of 390n H.

Allied Electronics:
Inductor; Shielded Power; AEC-Q200; 0.39uH20% SMT 1038

Chip1Stop:
Inductor Power Shielded Wirewound 390nH 20% 100KHz 15Q-Factor Carbonyl Powder 30A 1.3mOhm DCR 4040 Automotive T/R

Verical:
Inductor Power Shielded Wirewound 0.39uH 20% 100KHz 15Q-Factor Carbonyl Powder 30A 0.0013Ohm DCR 4040 Automotive T/R

Newark:
# BOURNS  SRP1038A-R39M  Surface Mount Power Inductor, SRP1038A Series, 390 nH, 30 A, 60 A, Shielded, 1300 µohm

Online Components:
Inductor Power Shielded Wirewound 390nH 20% 100KHz 15Q-Factor Carbonyl Powder 30A 1.3mOhm DCR 4040 Automotive T/R

Electro Sonic:
Inductor Power Shielded Wirewound 390nH 20% 100KHz 15Q-Factor Carbonyl Powder 30A 1.3mOhm DCR 4040 Automotive T/R
