SRP7030-8R2M

8.2uH ±20% 4A

屏蔽 绕线 器 68 毫欧最大 非标准

得捷:
FIXED IND 8.2UH 4A 68 MOHM SMD

艾睿:
Is space on a PCB a limiting factor for your electronic circuit design? Then use this power SRP7030-8R2M surface mount inductor from Bourns to save valuable space. This SMD inductor has a minimum operating temperature of -55 °C and a maximum of 150 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. It has a tolerance of 20%. This SMD inductor has a maximum DC current of 4 A with a maximum resistance of 68m Ohm. This product is 7.8 mm long, 3.2 mm tall and 7 mm deep. It has an inductance of 8.2u H. This device is made with wirewound technology. Its test frequency is 100K Hz.

安富利:
Ind Power Shielded Wirewound 8.2uH 20% 100KHz Iron 4A T/R

Chip1Stop:
Inductor Power Shielded Wirewound 8.2uH 20% 100KHz Iron 4A 68mOhm DCR T/R

Verical:
Inductor Power Shielded Wirewound 8.2uH 20% 100KHz Iron 4A 0.068Ohm DCR T/R

MASTER:
Inductor Power Shielded Wirewound 8.2uH 20% 100KHz Iron 4A 68mOhm DCR T/R

Online Components:
Inductor Power Shielded Wirewound 8.2uH 20% 100KHz Iron 4A 68mOhm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 8.2uH 20% 100KHz Iron 4A 68mOhm DCR T/R
