SRR0908-222YL
数据手册.pdf屏蔽贴片功率电感 SMD Shielded Power Inductors
屏蔽 绕线 器 5 欧姆最大 8-SMD，鸥翼
立创商城:
2.2mH ±15% 200mA 5Ω
得捷:
FIXED IND 2.2MH 200MA 5 OHM SMD
贸泽:
Fixed Inductors 2200uH 15% SMD 0908
艾睿:
Use this power SRR0908-222YL surface mount inductor from Bourns to make any circuit look clean and compact. This SMD inductor has an operating temperature range of -40 °C to 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This device utilizes wirewound technology. This product is 10.5 mm long, 7.8 mm tall and 13 mm deep. It has a tolerance of 15%. This SMD inductor has a maximum DC current of 200m A with a maximum resistance of 5 Ohm. It has an inductance of 2.2m H. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 1M Hz.
安富利:
Ind Power Shielded Wirewound 2.2mH 15% 1KHz 95Q-Factor Ferrite 200mA T/R
Verical:
Inductor Power Shielded Wirewound 2200uH 15% 1KHz 95Q-Factor Ferrite 0.2A 5Ohm DCR T/R
Online Components:
Inductor Power Shielded Wirewound 2.2mH 15% 1KHz 95Q-Factor Ferrite 200mA 5Ohm DCR T/R
Electro Sonic:
Inductor Power Shielded Wirewound 2.2mH 15% 1KHz 95Q-Factor Ferrite 200mA 5Ohm DCR T/R
